4-Stub Data Bus Couplers MIL-STD-1553B

Part # Feature Specification
90-50204 bus & stub jacks TRB 3-lug jacks
MSX000016 tech note non-terminated
bus termination none
90-50204
MSX000016

Part # Feature Specification
90-50214 bus & stub jacks TRB 3-lug jacks
MSX000017 tech note single-terminated
bus termination one 78.7 ohm resistor
90-50214
MSX000017

Part # Feature Specification
90-51214 bus & stub jacks TRB 3-lug jacks
MSX000018 tech note single-terminated
bus termination one 78.7 ohm resistor
90-51214
MSX000018

Part # Feature Specification
C
90-52214 bus & stub jacks TRB 3-lug jacks
M
MSX000019 tech note single-terminated
Y
bus termination one 78.7 ohm resistor
90-52214
CM
MSX000019
MY
CY Part # Feature Specification
CMY 90-50224 bus & stub jacks TRB 3-lug jacks
K MSX000020 tech note dual-terminated
bus termination two 78.7 ohm resistors
90-50224
See our website, MilesTek.com for detailed information. MSX000020

Halogen Free Cable Assemblies

Item # Description
Halogen Free Cable Assembly TRB 3-Slot Plug to Insulated Bulk
MSA00228-12N Head 3-Lug Cable Jack MIL-STD-1553 .242" O.D. -30C +80C
78 Ohm Twinaxial Shielded Twisted Pair 1'
Halogen Free Cable Assembly TRB 3-Lug Cable Jack to Jack
MSA00234-12N MIL-STD-1553 .242" O.D. -30C +80C 78 Ohm Twinaxial Shielded
Twisted Pair 1'
MSA00228-12N MSA00234-12N
Halogen Free Cable Assembly TRB 3-Slot Plug to Plug with Bend
MSA00229-12N Reliefs MIL-STD-1553 .242" O.D. -30C +80C 78 Ohm Twinaxial
Shielded Twisted Pair 1'
Halogen Free Cable Assembly TRB 3-Slot Plug with Bend Relief
MSA00230-12N to Blunt MIL-STD-1553 .242" O.D. -30C +80C 78 Ohm Twinaxial
Shielded Twisted Pair 1'
MSA00229-12N MSA00230-12N
Custom connectorization and configuration options available.
