MIL-STD-1553B | Lab Twinax Assemblies

30-02001 Cable - Lab-Rated Pvc, 0.242 Inch Overall Diameter
xxx = cable length in inches xxx = cable length in inches
CA-2009-72 = 6 ft. (72 in.) CA-2009-xxx assembly MP-2151-120 = 10 ft. (120 in.) MP-2151-xxx assembly

Connector Part Number Connector Connector Part Number Connector
10-06030-210 10-06030-210 10-06033-210 10-06033-210
straight CA-2009-xxx straight bend relief, straight MP-2151-xxx bend relief, straight
3-slot solder/clamp plug 3-slot solder/clamp plug 3-slot solder/clamp plug 3-slot solder/clamp plug

Connector Part Number Connector Connector Part Number Connector
10-06030-210 blunt 10-06033-210 blunt
straight CA-2219-xxx - bend relief, straight MP-2156-xxx -
3-slot solder/clamp plug no connector 3-slot solder/clamp plug no connector

Connector Part Number Connector Connector Part Number Connector
10-06030-210 10-06031-210 10-06031-210 blunt
straight CA-2171-xxx straight straight MP-2357-xxx -
3-slot solder/clamp plug 3-slot solder/clamp plug 3-slot full crimp plug no connector

C
M
Connector Part Number Connector Connector Part Number Connector
Y
10-06030-210 10-06575-210 10-06033-210 10-06570-210
CM straight MP-2177-xxx straight bend relief, straight MP-2396-xxx bend relief, straight
3-slot solder/clamp plug 3-lug solder/clamp jack 3-slot solder/clamp plug 3-lug solder/clamp jack
MY
CY
CMY
Connector Part Number Connector Connector Part Number Connector
K
10-06030-210 10-06577-210 10-06033-210 10-06579-210
straight MP-2268-xxx non-isolated bend relief, straight MP-2624-xxx non-isolated, bend relief
3-slot solder/clamp plug 3-lug bulkhead jack 3-slot solder/clamp plug 3-lug bulkhead jack

Connector Part Number Connector Connector Part Number Connector
10-06030-210 10-06573-210 10-06033-210 10-06574-210
straight MP-2192-xxx isolated bend relief, straight MP-2414-xxx isolated, bend relief
3-slot solder/clamp plug 3-lug bulkhead jack 3-slot solder/clamp plug 3-lug bulkhead jack

Connector Part Number Connector Connector Part Number Connector
10-06575-210 10-06575-210 10-06570-210 10-06570-210
straight MP-2218-xxx straight bend relief, straight MP-2540-xxx bend relief, straight
3-lug solder/clamp jack 3-lug solder/clamp jack 3-lug solder/clamp jack 3-lug solder/clamp jack

Connector Part Number Connector Connector Part Number Connector
10-06575-210 blunt 10-06030-210 10-09030-210
straight MP-2275-xxx - straight CA-2253-xxx straight
3-lug solder/clamp jack no connector 3-slot solder/clamp plug threaded plug
