Twinaxial TRB 3-slot Full Crimp Cable Plug for Twinaxial Cable (.150" OD)
Like solder/clamp TRB connectors, full crimp TRB
plugs comply with RoHS regulations, and use the standard bayonet mating style.
The concentric twinaxial design includes a center contact, surrounded by a
second intermediate cylindrical contact. The bayonet mating interface helps
maintain stable connections, even under severe vibration. This plug is designed
to crimp with high-temperature 30-02003 and TWC-78-1 twinax cable.
Tech Notes - The center contact is high (positive) connected to the twinax blue wire and the cylindrical contact is low (negative) connected to the twinax white wire. The connector body is tied to the cable shield. Full crimp connectors require specialized tools.
Part Number: 010-0044010-0044 Trompeter Center Pin Positioner for M22520/1-01 Center contact crimp tool$299.99
Part Number: M22520/5-01Bushing Shield Crimp Tool$487.99
Part Number: M22520/1-01Center Contact Crimp Tool$422.99
Part Number: TWC-78-1TWC-78-1 Trompeter Twinaxial Cable Blue jacket 78 ohm 1553B$3.35
Part Number: Y778Bushing Shield Crimp Die Set (CD5-8)$829.00
Part Number: 30-0200378 ohm Twinaxial Cable (0.150" OD)$2.63
