4-Stub Couplers

Available in single-terminated double-terminated or non-terminated varieties, these inline couplers provide a means of adding a 4 stubs to a bus network.
  1. Two Stub Leads Left and Two Stubs Leads Right

    Dual-terminated bus couplers can be used as a self-contained, stand-alone bus network.  These inline couplers contain an internal bus that allows four stub leads to communicate with one another.

  2. One Stub Lead Left and Three Stub Leads Right

    Dual-terminated bus couplers can be used as a self-contained, stand-alone bus network.  These inline couplers contain an internal bus that allows four stub leads to communicate with one another.

  3. Bus Lead and Two Stub Leads Left and Bus Lead and Two Stub Leads Right

    These inline bus couplers allow for insertion of four stub leads into a bus network.  With bus leads to the left and the right, these non-terminated couplers are meant to be installed into an existing, terminated bus.

  4. Bus Lead and Two Stub Leads Left and Two Stub Leads Right

    These single-terminated inline bus couplers are designed to add an additional four stub leads onto the end of a bus network.  With built in electrical termination, these couplers reduce electrical interference by minimizing signal reflection.

  5. Bus Lead and Stub Lead Left and Three Stub Leads Right

    These single-terminated inline bus couplers are designed to add an additional four stub leads onto the end of a bus network.  With built in electrical termination, these couplers reduce electrical interference by minimizing signal reflection.
